Reference : CAPEL-105M

Capel-205 is a new generation capillary electrophoresis system with advanced options and design. Its main features are:

• Extended autosampler capacity up to 59 positions, allowing to provide overnight analyses
• Standard centrifuge-type vials of 1.5mL volume (Eppendorf-type) closed with their original caps are used for all solutions
• Specially designed unit automatically opens vials just prior to their use, thus preventing evaporation and any kinds of cross-contamination
• New HV block provides voltage up to +/- 30 kV thus improving separation efficiency and decreasing analysis time
• Optionally – integrated unit to control the state of the inner capillary surface provides significantly improved migration time reproducibility especially when analyzing samples with complex matrices

Thus Capel-205 can be the very best choice not only for R&D and low-scale analyses but also for the customers dealing routinely with dozens of samples per day.

Features and Benefits

Extended instrumental options

• Extended autosampler capacity up to 59 positions – hundreds of samples per months can be analyzed
• Integrated vials caps removal – all solutions are kept in the autosampler tightly closed excluding evaporation and cross-contamination
• New HV block provides voltage up to +/- 30 kV – separation efficiency is improved and analysis time is decreased
• Redesigned capillary cassette – length of the thermostated part of the capillary is increased to improve migration time reproducibility
• Spectra scanning facilitates peak identification
• Broad range of controlled injection pressure allows analysis of viscous samples
• Reverse sample injection under vacuum: ultra-short analysis time (less than 1 min) and sample stacking to decrease detection limit

Precise and highly effective capillary thermostating provided by circulating liquid coolant (water)(± 0.1 C)

• Extended range of applied buffers and increased efficiency in separation

Powerful software package "Elforun"

• Modified Elforun-205 to become even more user-friendly when operating with extended autosampler capacity
• Increased flexibility in performing analyses of various complexity
• Any kinds of complex runs are possible including those with pre-programming of changes in analysis conditions
• Customized report, data export to other programs

Unique design of the capillary cassettes

• Enlarged thermostatic part of the capillary improves migration time reproducibility
• Easy capillary change in just a few minutes
• Lower Detection Limit due to the optimized optical scheme

Reference : CAPEL-105M

CAPEL-105M is a capillary electrophoresis system for fast and effective solutions for food industry, environmental applications, pharmaceutical and chemical industries, biochemistry and forensic science.

Features and Benefits

Extended instrumental options

• Spectra scanning facilitates peak identification
• Broad range of controlled injection pressure allows analysis of viscous samples
• Reverse sample injection under vacuum: ultra-short analysis time (less than 1 min) and sample stacking to decrease detection limit

Precise and highly effective capillary thermostating provided by circulating liquid coolant (water)(± 0.1 C)

• Extended range of applied buffers and increased efficiency in separation

Powerful software package "Elforun"

• Increased flexibility in performing analyses of various complexity
• Any kind of complex runs are possible including those with pre-programming of changes in analysis conditions
• Customized report, data export to other programs

Unique design of the capillary cassettes

• Easy capillary change in just a few minutes
• Lower Detection Limit due to the optimized optical scheme
